How Keybindings Work

Section summary All 100 actions are centrally managed by KeyBindingService (App.KeyBindings). Macro shortcuts join the same table as Macro.<id>, so duplicates — and the case of binding one to the start of a two-key chord — get caught. Your bindings are saved in WindowSettings.CustomKeyBindings (List<KeyBindingDto>?). Bindings are entered in the Shortcut Keys tab (click → press key to record). On change, BindingsChanged fires and RebuildInputBindings() + UpdateShortcutTooltips() re-apply across all windows.

Control Deck Shortcut Keys tab: over 100 actions listed by group, each row with action name, current binding display, HotkeyRecorderControl (click → press key to record), per-row Reset button; "Export" and "Import" buttons at the bottom

  • Centralized key matching: Key handling throughout the app goes through KeyBindings.Matches(actionId, key, modifiers), so a remapped key works everywhere. Only keys that should stay fixed — a dialog's Esc / Enter, standard arrow-key movement — are checked directly and cannot be remapped.
  • Export / Import: Control Deck → Shortcut Keys → Export button writes current bindings to JSON. JSON shape: [{ "ActionId": "Rename", "Key": "F2", "Modifiers": "None" }, ...]. Import reads the same shape and overwrites existing bindings.
  • Per-row reset: Each action row has a "Reset" button that restores the default (removes just that row from CustomKeyBindings).
  • Tooltips: Each command button's tooltip auto-updates to include the current key (e.g., Rename (F2)). When a binding changes, UpdateShortcutTooltips() redraws all tooltips.
  • Action definitions: The authoritative list lives in KeyBindingService.RegisterDefaults(). To add one, call Register(...) there and add the localisation keys to all 10 lang/*.json files.
  • Key schemes (presets): Dropping one JSON file into data/keymaps/ adds a preset. Each entry is { "actionId", "key", "modifiers", "key2", "modifiers2" } — omit key2 for a single stroke, supply it for a two-key chord.
  • Never leave an operation out of reach: If something can be done from the screen but has no key, register it as an action with no key assigned so it can still be called by name from the command palette (Ctrl+Shift+P).
